Outline of product

The picture library, VT-7009, is a license option for the VG-876/879 series digital video signal generator.
It contains 14 natural images and scale patterns for evaluating High Dynamic Range (HDR).

Main Features

●8K (7680 x 4320) and 4K (3840 x 2160) images with 10 and 12-bit versions to choose from
●HDR standards of SMPTE ST 2084 (1000nits, 4000nits), HLG and SDR each format
●Supports ITU-R BT.2020 (Rec.2020) color space
●14 various natural pictures and scale patterns are provided.
●Includes a reference manual that indicates proper evaluation of luminance, color, gradation and solidity
●Easy operation by calling image number stored on a USB memory drive, in a format of the signal generator (VGD format)


Format, Color Depth
ResolutionColor DepthShooting Format
8K (7680 x 4320)10-bit, 12-bit each

SMPTE ST 2084 (1000nits, 4000nits), HLG,
SDR each

4K (3840 x 2160)10-bit, 12-bit eachSMPTE ST 2084 (1000nits, 4000nits), HLG,
SDR each
Storage MediaUSB Memory Drive(2 pcs)

image Data
