Outline of product
SD-7077 is a converter that supports 8K and 4K and outputs HDMI 2.1 signal to HDMI 2.0 signal in 4 divisions.
Useful for connecting to large LED visions and multi-display systems.
Features
・HDMI 2.1(FRL)x1 to HDMI 2.0(TMDS) x4 divisions output
・Supports various formats
7680×4320 60p/59.94p/50p/30p/29.97p/25p/24p/23.98p
3840×2160 120p/119.88p/100p
・Supports HDCP1.4 and 2.3
・Small size and lightweight
Connection example
Specifications
| HDMI2.1 input FRL10Gbps/ 4Lane, CTA-861-G, compliant, DSC non-compliant | HDMI 2.0 output (format per one) TMDS 18Gbps, CTA-861-G, HDCP compliant, DSC non-compliant | ||||
|---|---|---|---|---|---|
| Format | Color Space | bit | Format | Color Space | bit |
| 7680×4320 50p/59.94p/60p | YCBCR 4:2:0 | 8/10 | 3840×2160 60p/59.94p/50p | RGB/YCBCR 4:4:4 | 8 |
| 3840×2160 60p/59.94p/50p | YCBCR 4:2:2 | 8/10/12 | |||
| 3840×2160 30p/29.97p/25p/24p/23.98p | RGB/YCBCR 4:4:4 | 8/10/12 | |||
| 3840×2160 30p/29.97p/25p/24p/23.98p | YCBCR 4:2:2 | 8/10/12 | |||
7680×4320 | RGB/YCBCR 4:4:4 | 8/10 | 3840×2160 60p/59.94p/50p | RGB/YCBCR 4:4:4 | 8 |
| 3840×2160 60p/59.94p/50p | YCBCR 4:2:2 | 8/10/12 | |||
| 3840×2160 30p/29.97p/25p/24p/23.98p | RGB/YCBCR 4:4:4 | 8/10/12 | |||
| 3840×2160 30p/29.97p/25p/24p/23.98p | YCBCR 4:2:2 | 8/10/12 | |||
| 7680×4320 30p/29.97p/25p/24p/23.98p | YCBCR 4:2:2 | 8/10/12 | 3840×2160 60p/59.94p/50p | RGB/YCBCR 4:4:4 | 8 |
| 3840×2160 60p/59.94p/50p | YCBCR 4:2:2 | 8/10/12 | |||
| 3840×2160 30p/29.97p/25p/24p/23.98p | RGB/YCBCR 4:4:4 | 8/10/12 | |||
| 3840×2160 30p/29.97p/25p/24p/23.98p | YCBCR 4:2:2 | 8/10/12 | |||
3840×2160 | RGB/YCBCR 4:4:4 | 8/10 | 1920×1080 120p/119.88p/100p | RGB/YCBCR 4:4:4 | 8/10/12 |
| 1920×1080 120p/119.88p/100p | YCBCR 4:2:2 | 8/10/12 | |||
| 1920×1080 60p/59.94p/50p | RGB/YCBCR 4:4:4 | 8/10/12 | |||
| 1920×1080 60p/59.94p/50p | YCBCR 4:2:2 | 8/10/12 | |||
| 3840×2160 120p/119.88p/100p | YCBCR 4:2:2 | 8/10/12 | 1920×1080 120p/119.88p/100p | RGB/YCBCR 4:4:4 | 8/10/12 |
| 1920×1080 120p/119.88p/100p | YCBCR 4:2:2 | 8/10/12 | |||
| 1920×1080 60p/59.94p/50p | RGB/YCBCR 4:4:4 | 8/10/12 | |||
| 1920×1080 60p/59.94p/50p | YCBCR 4:2:2 | 8/10/12 | |||
| Audio Format | |
|---|---|
| Sample Frequency | 48kHz |
| Resolution | 24bit |
| Number of channels | Up to 8 channels |
General Specifications | |
|---|---|
| Power Requirements | DC 12V |
| Power Consumption | 30W MAX |
| Operating Temperature Range | 0～40℃ |
| Operating Humidity Range | 20～80％ RH (no condensation) |
| External Dimensions | 210(W) × 44(H) × 210(D)mm (excluding protrusions) |
| Weight | 2.0 kg |
